| Type | Injector Valve Set |
| Part Number | F00RJ01692 |
| Application | For Diesel Engine |
| Quality | China Made New |
| SKU | G1S8F00RJ01692 |
| G1L10F00RJ01692/G1L10F00RJ01692 | |
| G1N1F00RJ01692/N10000B2BJ01692 | |
| G1F2F00RJ01692/F20000B2BJ01692 | |
| MOQ | 4 pcs |
| Size | 13 cm*2 cm *2 cm |
| Weight | 0.03kg |
WE GIVE YOU MORE
Lorem ipsum dolor sit amet, consectetur adipiscing elit。Ut elit tellus、luctus nec ullamcorper mattis、pulvinar dapibus leo。
Lorem ipsum dolor sit amet, consectetur adipiscing elit。Ut elit tellus、luctus nec ullamcorper mattis、pulvinar dapibus leo。
Owners Manuals
Lorem ipsum dolor sit amet, consectetur adipiscing elit.Utelit tellus,luctus nec ullamcorper mattis,pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Utelit tellus, luctus nec ullamcorper mattis,pulvinar dapibus leo.
1. F00RJ01692 CRDI Injector Valve Set Introduction
1.1. F00RJ01692 CRDI Injector Valve Set Basic Information
| Title | F00RJ01692 CRDI Injector Valve Set China Made New |
| SKU1 | G1S8F00RJ01692 |
| SKU2 | G1L10F00RJ01692/G1L10F00RJ01692 |
| SKU3 | G1N1F00RJ01692/N10000B2BJ01692 |
| SKU4 | G1F2F00RJ01692/F20000B2BJ01692 |
1.2. F00RJ01692 CRDI Injector Valve Set Application Information
- F00RJ01692 CRDI Injector Valve Set Adapted Vehicle Information
| Injector Part Number | Car Model | OE Number | OE Number |
| 0 445 120 081 | FAW | 1112010B470-0000 | / |
| WUXI SIDA DIESEL ENGINE | 1112010 470 | / | |
| 0 445 120 107 | WEICHAI POWER CO.LTD. | 13035011 | / |
| 0 445 120 129 | WEICHAI POWER CO.LTD. | 612600080611 | 612600080971 |
| 0 445 120 130 | WEICHAI POWER CO.LTD. | 612600080618 | / |
| 0 445 120 149 | WEICHAI POWER CO.LTD. | 612600080611 | / |
| 0 445 120 150 | WEICHAI POWER CO.LTD. | 13024966 | / |
| 0 445 120 153 | KAMAZ | 201149061 | 004510411120349088 |
| 0 445 120 163 | YUCHAI MACHINERY | G5A00 1112100 A38 | / |
| 0 445 120 169 | WEICHAI POWER CO.LTD. | 612600080 924 | / |
| 0 445 120 170 | WEICHAI POWER CO.LTD. | 612600080618 | / |
| 0 445 120 191 | WEICHAI POWER CO.LTD. | 13034027 | / |
| 0 445 120 200 | WEICHAI POWER CO.LTD. | 612600080972 | / |
| 0 445 120 213 | WEICHAI POWER CO.LTD. | 612600080611 | / |
| 0 445 120 214 | WEICHAI POWER CO.LTD. | 612600080924 | / |
| 0 445 120 222 | WEICHAI POWER CO.LTD. | 612600080964 | / |
| 0 445 120 224 | WEICHAI POWER CO.LTD. | 612600080618 | / |
| 0 445 120 226 | YUCHAI MACHINERY | G6A00-1112100-A38 | / |
| 0 445 120 227 | WEICHAI POWER CO.LTD. | 612600080977 | / |
| 0 445 120 228 | WEICHAI POWER CO.LTD. | 612600080978 | / |
| 0 445 120 244 | WEICHAI POWER CO.LTD. | 13024966 | / |
| 0 445 120 260 | WEICHAI POWER CO.LTD. | 13034028 | / |
| 0 445 120 324 | FAW | 1112010-440-0000 | / |
| 0 445 120 331 | FAW | 1112010-470-0000BL | / |
| 0 445 120 343 | WEICHAI POWER CO.LTD. | 612640080031 | / |
| 0 445 120 344 | WEICHAI POWER CO.LTD. | 612640080022 | / |
| 0 445 120 357 | SINOTRUK (CNHTC) | VG1034080002 | / |
| 0 445 120 379 | YUCHAI MACHINERY | A2000-1112100-A38 | / |
| 0 445 120 380 | YUCHAI MACHINERY | J2000-1112100-A38 | / |
| 0 445 120 410 | YUCHAI MACHINERY | E4700-1112100-A38 | / |
| 0 445 120 459 | WEICHAI POWER CO.LTD. | 13074417 | / |
| 0 445 120 468 | / | / | / |
| 0 445 120 530 | / | / | / |
| 0 445 120 533 | / | / | / |
- F00RJ01692 CRDI Injector Valve Set Adapted injector Information
| Injector Series | Injector Part Number | System Pressure | Re-manufactured Part Number | System Pressure | Universal Number | System Pressure | Universal Number | System Pressure |
| CRIN2-16 | 0 445 120 081 | 1600 | / | / | / | / | / | / |
| CRIN2-16 | 0 445 120 107 | 1600 | / | / | / | / | / | / |
| CRIN2-16 | 0 445 120 129 | 1600 | / | / | / | / | / | / |
| CRIN2-16 | 0 445 120 130 | / | / | / | 0 445 120 222 | 1600 | / | / |
| CRIN2-16 | 0 445 120 149 | / | 0 986 AD1 007 | / | 0 445 120 213 | 1600 | / | / |
| CRIN2-16 | 0 445 120 150 | / | / | / | 0 445 120 244 | 1600 | / | / |
| CRIN2-16 | 0 445 120 153 | 1600 | / | / | / | / | / | / |
| CRIN2-16 | 0 445 120 163 | 1600 | 0 986 AD1 039 | 1600 | 0 445 120 226 | 1600 | 0 445 120 433 | 1600 |
| CRIN2-16 | 0 445 120 169 | / | 0 986 AD1 009 | / | 0 445 120 214 | 1600 | / | / |
| CRIN2-16 | 0 445 120 170 | / | 0 986 AD1 010 | 1600 | 0 445 120 224 | 1600 | / | / |
| CRIN2-16 | 0 445 120 191 | 1600 | / | / | / | / | / | / |
| CRIN2-16 | 0 445 120 200 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 213 | 1600 | 0 986 AD1 007 | 1600 | / | / | / | / |
| CRIN2-16-BL | 0 445 120 214 | 1600 | 0 986 AD1 009 | 1600 | / | / | / | / |
| CRIN2-16-BL | 0 445 120 222 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 224 | 1600 | 0 986 AD1 010 | 1600 | / | / | / | / |
| CRIN2-16-BL | 0 445 120 226 | 1600 | 0 986 AD1 039 | 1600 | 0 445 120 433 | 1600 | / | / |
| CRIN2-16-BL | 0 445 120 227 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 228 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 244 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 260 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 324 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 331 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 343 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 344 | 1600 | / | / | / | / | / | / |
| CRIN2-16-BL | 0 445 120 357 | 1600 | / | / | 0 445 120 446 | 1600 | / | / |
| CRIN2-16-BL | 0 445 120 379 | 1600 | / | / | 0 445 120 429 | 1600 | / | / |
| CRIN2-16-BL | 0 445 120 380 | 1600 | / | / | 0 445 120 427 | 1600 | / | / |
| CRIN2-16-BL | 0 445 120 410 | 1600 | / | / | 0 445 120 436 | / | / | / |
| CRIN2-16-BL | 0 445 120 459 | 1600 | / | / | / | / | / | / |
| CRIN2;CR/IPL24/ZERES20S | 0 445 120 468 | / | / | / | / | / | / | / |
| CRIN2-16BL;CR/IPL24/ZERES20S | 0 445 120 530 | / | / | / | / | / | / | / |
| CRIN2-16BL;CR/IPL24/ZERES20S | 0 445 120 533 | / | / | / | / | / | / | / |
1.3. F00RJ01692 CRDI Injector Valve Set Specifications and Dimensions Parameters
CRDI Injector Valve Set Size： 13 cm*2 cm *2 cm
CRDI Injector Valve Set Box Size：14 cm *3 cm *3 cm
CRDI Injector Valve Set Packing Size：31 cm *12 cm
CRDI Injector Valve Set Net Weight：0.03kg
CRDI Injector Valve Set Gross Weight：0.03kg
CRDI Injector Valve Set Quality：China Made New
CRDI Injector Valve Set MOQ：4PC
2. F00RJ01692 CRDI Injector Valve Set Quality Control
- CRDI Injector Valve Set Testing
All parts of the CRDI injector valve set have undergone precision testing, high temperature testing, low temperature testing, withstand pressure testing, leakage testing, durability testing, and various working conditions testing.
- CRDI Injector Valve Set Inspection
The factory inspection of the CRDI injector valve set is undergone three inspections: full inspection, random inspection, and batch inspection. Different brands of test benches are used to test the same CRDI injector valve set for more than three times for factory inspection, and the CRDI injector valve set ‘s installation and testing environment are progressed in dust-free workshop.
- CRDI Injector Valve Set Installation
When matching the valve cap and valve steam, Shumatt strictly complies with the standard of valve cap and valve stem clearance technical indicators to ensure that each CRDI injector valve set meets the factory standards and use standards.
3. F00RJ01692 CRDI Injector Valve Set Customized Service
- CRDI Injector Valve Set Customized Service Coverage：Meet the customized needs of OEM manufacturers for valve color and lustre, valve cap groove customization, valve cap lettering ,valve cap logo engraving, valve cap QR code engraving, CRDI injector valve set internal packaging, CRDI injector valve set external packaging and label customization needs.
| No. | 1 | 2 |
| Image |  |
 |
| Name | Valve Cap Color And Lustre | Valve Cap Color And Lustre |
| Description | Customized 1000 pieces (white color is optional) | Customized 1000 pieces (purple red color is optional ) |
| No. | 3 | 4 |
| Image |  |
 |
| Name | Valve Cap Groove Customization | Valve Cap Lettering, Logo Engraving, QR Code Engraving Customization |
| No. | 5 | 6 |
| Image |  |
 |
| Name | Valve Set Box | Valve Set Box |
| Description | Rectangle is optional | Cylindrical is optional |
| No. | 7 | 8 |
| Image |  |
 |
| Name | Valve Set Bag | Valve Set Label 7cm*5cm |
- CRDI Injector Valve Set Customized Service Requirements：
The purchase of customized CRDI injector valve set package is no less than 100 pieces.
The purchase of customized CRDI injector valve set groove is no less than 100 pieces.
The purchase of customized CRDI injector valve set is no less than 1000 pieces.
The purchase of customized CRDI injector valve cap engraving is no less than 1000 pieces.
The purchase of customized CRDI injector valve color is no less than between 1000 -10000 pieces.
When the customized pstemucts involve the need of specify logo, the OEM manufacturer is asked to provide trademark authorization and the sample of logo image file.
Once the customized CRDI injector valve set is sold, it can not be returned or exchanged if there is no quality problems.
4. F00RJ01692 CRDI Injector Valve Set Warranty Instructions
- CRDI Injector Valve Set Warranty Conditions and Instructions
It is necessary to provide pictures, videos, or test reports detected by the CRDI injector valve set inspection equipment when the valve set is abnormal during use as evidence to feed back to the salesman.
Abnormal conditions are properly explained such as:1.Smoke, 2. Engine shake, 3. Difficulty starting the engine, 4. Engine noise, 5.Oil leakage and other abnormal conditions.
The above condition may also be affected by other components of the injector. If it is confirmed by our company to be a pstemuct problem, it is within the scope of the subsidy.
- CRDI Injector Valve Set Warranty Coverage
Within 15 days after customer receives the F00RJ01692 CRDI injector valve set, if there is a performance failure and the pstemuct has no appearance damage, customer can choose to replace it;
If the F00RJ01692 CRDI injector valve set has performance problems during the warranty period (6-12 months), and it is confirmed that it is pstemuct’s problems after being tested, you can contact our salesmen to replace the same model for free;
If the pstemuct is confirmed to be fault-free, the pstemuct will be returned.
5. F00RJ01692 CRDI Injector Valve Set Purchase and Delivery.
5.1. F00RJ01692 CRDI Injector Valve Set Purchase Payment Terms
Payment Terms： T/T, PayPal, Alipay, WeChat
- Please contact our salesmen for specific payment information.
5.2. F00RJ01692 CRDI Injector Valve Set Shipping Ways
Destination in China areas: SF Express, Debon Express, the corresponding logistics company can be provided according to customer requirements in special cases.
Destinations out of China’s areas：DHL, UPS, FedEx, TNT air, ocean or other shipping methods required by customers.
5.3. F00RJ01692 CRDI Injector Valve Set Lead Time
Lead time：Send out within 3 – 7 working days after receiving payment(Except for special pstemucts and special cases).
